Stacked Bar Chart

StackedBarChart renders multiple series as stacked segments within each category's bar.

The example below is minimal and runs as written. The GIF above uses a longer generated series per channel; its full source is in StackedBarExample.kt.

@Composable
fun ShowStackedBar() {
    val data = listOf(
        "Online" to listOf(280.0, 520.0, 760.0, 1080.0),
        "Retail" to listOf(480.0, 760.0, 1050.0, 1400.0),
        "Wholesale" to listOf(360.0, 540.0, 620.0, 720.0),
    ).toChartData(
        categories = listOf("Q1", "Q2", "Q3", "Q4"),
    )

    StackedBarChart(data = data, title = "Quarterly Revenue by Channel")
}

Formatting

StackedBarChart(
    data = data,
    title = "Quarterly Revenue by Channel",
    selectedValueFormatter = ChartValueFormatters.prefix("$"),
    axisValueFormatter = ChartValueFormatter { value ->
        "$" + StackedBarChartDefaults.axisValueFormatter.format(value)
    },
)

selectedValueFormatter formats the selected values, and axisValueFormatter formats the Y-axis labels. StackedAreaChart takes the same two formatters.

Gradients

Pass a shared ChartGradient to StackedBarChartDefaults.segments(gradient = ...) to use it for every segment. Stacked bars do not support separate gradients per series. See Gradients for details.

We currently recommend only fade gradients for stacked bar charts. Fades preserve each series' color. Gradients through multiple colors within a segment can make series hard to distinguish.

StackedBarChartDefaults.segments(
    gradient = ChartGradients.fade(endAlpha = 0.35f),
)
